Transcript library k-mer counts with Biostrings

Tareian Cazares

library(SeedMatchR)

Determine transcript library k-mer counts with Biostrings

This article will show you how to determine the transcriptome k-mer counts for your transcriptome of interest.

Find hg38 7-mer counts across canonical ENSEMBL transcripts

Load annotations

annodb <- load_annotations("hg38", feature.type = "exons")
#> Build AnnotationFilter for transcript features based on the following parameters:
#> Keep only standard chroms: TRUE
#> Remove rows with NA in transcript ID: TRUE
#> Keep only protein coding genes and transcripts: TRUE
#> Filtering for transcripts with support level: FALSE
#> Keep only the ENSEMBL canonical transcript: TRUE
#> Filtering for specific genes: FALSE
#> Filtering for specific transcripts: FALSE
#> Filtering for specific gene symbols: FALSE
#> Filtering for specific entrez id: FALSE
#> Warning: replacing previous import 'S4Arrays::makeNindexFromArrayViewport' by
#> 'DelayedArray::makeNindexFromArrayViewport' when loading 'SummarizedExperiment'
#> Loading annotations from AnnotationHub for hg38
#> downloading 1 resources
#> retrieving 1 resource
#> loading from cache
#> require("rtracklayer")
#> downloading 1 resources
#> retrieving 1 resource
#> loading from cache
#> require("ensembldb")
#> Extracting exons from ensembldb object.
#> Extracting sequences for each feature.
#> Keeping sequences that are >= 8

Create data frame for mapping tx_ix to gene_id

# Create a data frame to map tx_id to gene_id
tx2gene <- mcols(transcripts(annodb$txdb, columns=c("tx_id", "gene_id")))
#> Warning in valid.GenomicRanges.seqinfo(x, suggest.trim = TRUE): GRanges object contains 1 out-of-bound range located on sequence LRG_432.
#>   Note that ranges located on a sequence whose length is unknown (NA) or on a
#>   circular sequence are not considered out-of-bound (use seqlengths() and
#>   isCircular() to get the lengths and circularity flags of the underlying
#>   sequences). You can use trim() to trim these ranges. See
#>   ?`trim,GenomicRanges-method` for more information.
tx2gene$gene_id <- as.character(tx2gene$gene_id)

Get counts data

# only focus on ten sequences since the run can take a while during testing.
exon.counts = sequence_kmer_counts(annodb$seqs[1:10], tx2gene, width = 7)

exon.counts[1:3, 1:5]
#>             tx_id gene_id AAAAAAA AAAAAAC AAAAAAG
#> 1 ENSG00000004059    <NA>       0       0       0
#> 2 ENSG00000003056    <NA>       6       3       0
#> 3 ENSG00000173153    <NA>       1       0       0

Convert to K-mer summary table

exon.binary = as.matrix(exon.counts[3:ncol(exon.counts)])
exon.binary[exon.binary > 0] <- 1

exon.gene.counts = colSums(exon.binary)

exons.df = data.frame("exon.counts" = exon.gene.counts)

head(exons.df)
#>         exon.counts
#> AAAAAAA           5
#> AAAAAAC           3
#> AAAAAAG           4
#> AAAAAAT           4
#> AAAAACA           3
#> AAAAACC           3

hist(exon.gene.counts, breaks = 50, xlab = "Number of genes with 7mer", col = "grey90", main = NULL)
